HMI for Rubber and Plastic Industry

HMI for Rubber and Plastic Industry

The User Interface is visually pleasing, featuring clear images, high resolution, and seamless communication. Additionally, it supports multiple languages. It simplifies and makes easier the mechanical operation when used with Techmation controllers.

- Q8A Aluminum Casing -

- Q12A Aluminum Casing -

- Q12A All-in-One
(no operation box) -

- Q15AT All-in-One
(no operation box) -

- 15.6" All-in-One
(no operation box) -

- 18.5" All-in-One
(no operation box) -

- 21.5" All-in-One
(no operation box) -

Parameters

Q8A Aluminum Casing

Q12A Aluminum Casing

Q12A All-in-One
(no operation box)

Q15AT All-in-One
(no operation box)

15.6" All-in-One
(no operation box)

18.5" All-in-One
(no operation box)

21.5" All-in-One
(no operation box)

Q8A Aluminum Casing
Items	Specifications
Size W（mm）*L（mm）	47026041.2
CPU Frequency	800MHz
LCD Display	8.0"
LCD Resolution	800*600
Baud Rate	10/100Mbps
Operation Temperature	-10℃~50℃
Storage Temperature/RH	-20℃~85℃/85%RH
Communication Port	NET, RS232
Memory Card Port	USB

Q12A Aluminum Casing
Items	Specifications
Size W（mm）*L（mm）	55033563.4
CPU Frequency	800MHz
LCD Display	12.1"
LCD Resolution	800*600
Baud Rate	10/100Mbps
Operation Temperature	-10℃~50℃
Storage Temperature/RH	-20℃~85℃/85%RH
Communication Port	NET, RS232
Memory Card Port	USB

Q12A All-in-One (no operation box)
Items	Specifications
Size W（mm）*L（mm）	55033552.5
CPU Frequency	800MHz
LCD Display	12.1"
LCD Resolution	800*600
Baud Rate	10/100Mbps
Operation Temperature	-10℃~50℃
Storage Temperature/RH	-20℃~85℃/85%RH
Communication Port	NET, RS232
Memory Card Port	USB

Q15AT All-in-One (no operation box)
Items	Specifications
Size W（mm）*L（mm）	52327656
CPU Frequency	800MHz
LCD Display	15.0" Capacitive Touch Screen
LCD Resolution	1024*768
Baud Rate	10/100Mbps
Operation Temperature	-10℃~50℃
Storage Temperature/RH	-20℃~85℃/85%RH
Communication Port	NET, RS232
Memory Card Port	USB

15.6" All-in-One (no operation box)
Items	Specifications
Size W（mm）*L（mm）	47031762
CPU Frequency	1.2GHz 4-core
LCD Display	15.6" Capacitive Touch Screen
LCD Resolution	1920*1080
Baud Rate	10/100Mbps
Operation Temperature	-10℃~50℃
Storage Temperature/RH	-20℃~85℃/85%RH
Communication Port	NET, RS232, RS485
Memory Card Port	USB

18.5" All-in-One (no operation box)
Items	Specifications
Size W（mm）*L（mm）	55037462
CPU Frequency	1.2GHz 4-core
LCD Display	18.5" Capacitive Touch Screen
LCD Resolution	1920*1080
Baud Rate	10/100Mbps
Operation Temperature	-10℃~50℃
Storage Temperature/RH	-20℃~85℃/85%RH
Communication Port	NET, RS232, RS485
Memory Card Port	USB

21.5" All-in-One (no operation box)
Items	Specifications
Size W（mm）*L（mm）	62042562
CPU Frequency	1.2GHz 4-core
LCD Display	21.5" Capacitive Touch Screen
LCD Resolution	1920*1080
Baud Rate	10/100Mbps
Operation Temperature	-10℃~50℃
Storage Temperature/RH	-20℃~85℃/85%RH
Communication Port	NET, RS232, RS485
Memory Card Port	USB
